Advanced Handheld Fiber Test Kits

Title	Description	Price
TK076	Advanced Test Kit for Singlemode and Multimode	$4214.67
TK077	Advanced Test Kit for Singlemode	$3376.17
TK081	Pocket Light Source and Handheld Power Meter for Singlemode	$2713.24

Title

Description

Price

Resellers

TK076

Advanced Test Kit for Singlemode and Multimode

$4214.67

TK077

Advanced Test Kit for Singlemode

$3376.17

TK081

Pocket Light Source and Handheld Power Meter for Singlemode

$2713.24

Tempo Handheld Fiber Test Kits pair optical power meters with stabilized light sources to give technicians a reliable, field-ready solution for measuring optical power, insertion loss, and fiber continuity. Available in singlemode, multimode, standard, and high-power configurations, these kits support everyday fiber testing as well as more application-specific needs like out-of-band testing and tone identification. Choose the kit that matches your network, wavelength requirements, and testing workflow.

Typical testing applications

Optical power at 25 calibrated wavelengths, -60 to +15 dBm range.
Optical loss on SM fiber 1310 / 1550 nm, 60 dB range.
Optical loss on MM fiber 850 / 1300 nm, 40 dB (@ 62.5um) range, EF compliant.
Loss testing automation & reporting with AutoTest and KITS™ software.
Optical continuity / tone checking, 12 fiber Multi-Fiber ID, 50 dB range.
Generally meets safety regulations & standards based test procedures.

Connector & battery summary

SC interchangeable connector adapters.
Meter accepts PC & APC polish. Source accepts PC polish.
Meter 2 x AA alkaline. Run time >1000 hours. Micro USB pwr /charging.
Source 2 x AA alkaline. Run time >80 hours. Micro USB pwr /charging.

Attribute name	Attribute Value
Model	TK076	TK077	TK081
Detector type	InGaAs
Calibration accuracy	1% (0.06 dB)
Response wavelength	600 ~ 1700 nm
Calibration wavelengths	780, 820, 850, 980, 1270, 1290, 1300, 1310, 1330, 1350, 1370, 1390, 1410, 1430, 1450, 1470, 1490, 1510, 1530, 1550, 1570, 1590, 1610, 1625, 1650 nm
Power range	+10 ~ -60 dBm (for 780 ~ 980 nm) / +10 ~ -70 dBm (for 1270 ~ 1650 nm)
Mid-range linearity	0.04 dB (typical)
Total uncertainty	0.3 dB (max)
Wavelength sensitivity (± 30 nm)	0.03 dB (typical)
ID tone detection & Autotest sensitivity	Up to -50 dBm

Attribute name

Attribute Value

Model

TK076

TK077

TK081

Detector type

InGaAs

Calibration accuracy

1% (0.06 dB)

Response wavelength

600 ~ 1700 nm

Calibration wavelengths

780, 820, 850, 980, 1270, 1290, 1300, 1310, 1330, 1350, 1370, 1390, 1410, 1430, 1450, 1470, 1490, 1510, 1530, 1550, 1570, 1590, 1610, 1625, 1650 nm

Power range

+10 ~ -60 dBm (for 780 ~ 980 nm) / +10 ~ -70 dBm (for 1270 ~ 1650 nm)

Mid-range linearity

0.04 dB (typical)

Total uncertainty

0.3 dB (max)

Wavelength sensitivity (± 30 nm)

0.03 dB (typical)

ID tone detection & Autotest sensitivity

Up to -50 dBm

Typical testing applications

Connector & battery summary
