Dual LED Optical Test Source, T2803-50A

Cat No: T2803-50A

Contact Sales

The T2803-50A Handheld Fiber Sources are enhanced 850/1300nm LED sources designed for 50/125μm multimode fiber testing modified for industry specific launch conditions in the military and aviation. These customized instruments feature a 50μm output port with a predefined launch condition. No additional patch cords, launch cables or mandrel wraps are required. This reduces the risk of FOD and ensures no additional parts or accessories which could be left behind in an aircraft.

The T2803 series sources are used with optical power meters for testing optical loss on multimode fibers. A multi-fiber tone feature makes for handy continuity / polarity testing and fault finding, also for use with clip-on traffic identifiers.

OPTICAL COMMUNICATIONS TEST APPLICATIONS
• Enhanced 50/125μm multimode fiber testing at 850 & 1300nm
• Industry-specific launch conditions
• No additional mandrel wraps or patch cords required
• Multi-Fiber polarity checking and fiber identification
• Tone source for fiber identifier

Dual LED Optical Test Source, T2803-50A
    • 850 & 1300nm mode controlled multimode LED source
    • Industry-specific launch conditions for the military and aviation
    • Excellent optical power stability
    • ISO 17025 traceable calibration certificate
    • Compatible with all types of 50/125 micron fiber
    • No mandrel wraps required
    • Interchangeable connectors with dust cap / tilt bail
    • Excellent re-connection repeatability
    • Reliable, rugged & versatile, simple to use
    • LCD is large, clear, sunlight readable & backlit
    • Auto-test compatibility with other instruments
    • Optical test tone with Multi-fiber ID function
    • Long battery life
    • External power / charging via USB
    • 3 Year warranty
    • Made in Australia
Attribute Name Attribute Value
Output wavelength Port 2: 850, 1300 nm LED
Output power -20 dBm ±1 dB (@ 50/125 µm)
Short term stability (for 15 min, typical ±2 °C, after warm up, ORL < -25 dB) 0.01 dB
Stability over temperature 0.35 dB (typical)
Wavelength drift 0.4 nm /°C (typical)
Mode controlled source 50/125µm compliant: IEC 61280-4-1 {Ed.1.0}, TIA 526-14A & TIA TSB-178
Reconnection repeatability (95% confidence) 0.05 dB
Calibration validity (ISO/IEC 17025) 3 years
Modulated output 270 Hz, 1 kHz, 2 kHz ± 2 %, 12 Multi-Fiber ID tones
Autotest (not available for 470, 540 nm LED sources) Compatible with KI Autotest power meter port & matching λ
Power Battery / External power via USB
Battery types 2x AA (LR6) Alkaline / 2x AA NiMH AA (rechargeable via USB)
Battery life Laser/LED source: 90/80 hours in Autotest, typical
Auto off Selectable
Case Polycarbonate (body) / rubber (edges & corners), moisture resistance, 1-meter drop tested
Size 190 mm x 105 mm x 35 mm
Unit weight 0.42 kg
Shipping weight 1.5 Kg
Operating / storage temperature -15 to 55 °C / -25 to 70 °C
Relative humidity 0 ~ 95 %
Warranty 3 years
Country of Origin Australia
