TM-700 Tele-Mate Telephone Test Set

Catalog Number: TM-700
$243.08

The TEMPO Communications TM-700 telephone buttset helps technicians install, service, and maintain voice services with ease. DSL compatible in both Monitor and Talk modes, the TM-700’s LCD screen makes reading polarity, voltage, current, and ringing frequencies easier than ever, and clearly shows speed dials and recent numbers for faster access.

The TM-700 features over-voltage and over-current detection for safer operation and also features an intercom mode, a built-in toner for pair tracing, and DTMF detection and measurement for enhanced productivity. Use the built-in loudspeaker or with a headset (included) for easy hands-free operation.

The Tempo Communications TM-700 makes your job faster, safer, and easier.

  • Designed for comfortable shoulder placement. Operate in either hand, clip onto the belt, or use hands free.
  • Allows alerting and talking over a “dead” pair of wires.
  • A built-in pair tracing toner is provided. The frequencies chosen are suitable for use with Tempo probes, as well as any other probe that works in the audio range.
  • Make many jobs hands-free.
  • Advanced silicone rubber keypad glows after exposure to light, aiding operation in low light conditions.
  • LCD for easy dialing, programming, caller ID, voltage, current, ringing, and DTMF measurements
  • Safe over voltage and over current protection
  • Intercom for “dead-pair” talking
  • SmartIntercom™ between Tele-Mate® Pros (including PE830); allows “ringing” the far end
  • Tone generator for pair identification
  • Luminescent (glow-in-the-dark) keypad
  • DSL line filter
  • Super Impedance Amplifier to monitor lines without disrupting traffic
Document Icon TM 700 Datasheet
Document Icon TM-700 User Manual
Attribute NameAttribute Value
ApplicationTest Telephone (buttset) with High-impedance monitor, LCD, Smart Intercom, Calling Line ID, Pair tracing toner, DTMF decoding, Multiple last-number redial and ten speed-dial memories
DC VoltageTNV-3 working, 500 V peak, 1500 V TRANSIENT
Dimensions9.25 (235 MM) Length X 2.5 (64 MM) Width X 3.25 (83 MM) Height
Leakage> 10 M ohms
Loop Current<ul>< 10 mA < I < 125 mA</ul>
Replacement PartReplaces PE830, Spares CS-01,CS-02, CS-03, CS-04, CS-05, CS-06, CS-07, HS-001
StandardTIA/EIA-470-B and ETSI
StorageOperatingTemperature-10 C to +70 C, <95% humiditystorage, 0 C to +50 C, <90 % humidity (no condensation) operating
Voltage Measurement110 V dc max
