KIT LAN PRONAVIGATOR

Cat No: PA901066

Legacy UPC No: 769328108170

  • The LAN PRONAVIGATORTM provides simple PASS/FAIL test results in one second which allows technicians to quickly move on to the next test site.
  • Generates oscillating audio tone for use with tone probes to locate cables.
  • Tests data and telephone cables up to 320 feet (100 meters) for proper pairing for EIA/TIA-568A, EIA/TIA-568B, Token Ring, 10 Base T, and common Category 5. configurations.
  • Tests unshielded UTP and shielded STP data cable.
  • Detects good connections, open connections, crossed wires and split pairs.
  • Tests common BNC connected 50 and 75 ohm coaxial cables up to 320 feet (100 meters) for continuity.
  • Tests coaxial cable types RG58, RG59, RG6, RG6 Quad, Belden 8281, RG8, RG11 and more.
  • Belt clips provided and lanyard holes embedded in case to attach to belt or wrist.
  • Features low battery test and auto-off function to preserve battery life.
  • Includes standard 9V battery.

KIT LAN PRONAVIGATORKIT LAN PRONAVIGATOR
Attribute Name Attribute Value
Includes
  • 2 RJ45 Patch Cords
  • 2 BNC Coaxial Cables
  • 2 CATV F To BNC Adapters
  • 1 BNC/BNC Adapter
  • 1 Shielded RJ45 Coupler
  • 2 Belt Clips In Durable Case
  • Size 8.500 IN (216.000 MM) x 7.600 IN (193.000 MM) x 3.000 IN (76.000 MM)
    Sub Brand LAN ProNavigator
    Weight 2.000 OZ (1140.000 G)
    Item Status Date 01012009
    Country of Origin TW
    UNSPSC 43223332
    International Harmonize Code 9030400000
    RoHS Indicator U
    MSDS Update Flag N
